Multiquip DCA70SSIU4F 70kVa Multi Phase Super Silent Diesel Generator

Original price was: $89,485.00.Current price is: $54,120.52.

Orders over $1,500.00 must be placed by phone. Call or text 707-332-0703

Category: Tag:
Sale!
DCA70SSIU4F 45kVa Multi Phase Diesel Generato

Description

Multiquip DCA70SSIU4F 70kVa Multi Phase Diesel Generator

The Multiquip DCA70SSIU4F 70kVa Multi Phase Diesel Generator offers a prime rating of 56 kW (70 kVA) and a standby rating of 62 kW (77 kVA). 70 kVA Prime Output, Single/Three-Phase, Isuzu Tier 4 Final

MQ Power WhisperWatt Super-Silent portable generators provide reliable power to meet the most demanding requirements. They are designed and built to withstand tough environments at construction sites and provide dependable temporary power at entertainment venues and disaster recovery operations.

DCA70SSIU4F Features

Our patented open delta generator winding provides precise voltage control, allowing superior motor starting capability. An electronic governor maintains frequency to ± 0.25% from no load to full load. It features an auto start stop that allows the generator to start from a remote location. Includes Heavy duty, 4-cycle, direct injection, heated crankcase vent, turbocharged, charge air cooled, 1000W block heater, diesel engine provides maximum reliability. The unit features a powder-coated / e-coated, weatherproof steel housing that allows a substantially low operating noise level of 65 dB(A). A comprehensive analog control panel provides instrumentation including AC ammeter, AC voltmeter, frequency meter, AC circuit breaker, engine gauges and much more.

Freight must be manually calculated – please call in with your delivery destination and details.

Unit Specifications

Prime Rating 56 kW 70 kVA
Standby Rating 62 kW 77 kVA
Generator RPM 1800
Voltage – Three Phase 208, 220, 240, 416, 440, 460, 480V Switchable
Voltage – Single Phase 120, 127, 139, 240, 254, 277V Switchable
Generator Design Revolving field, Self-ventilated, Drip-proof, Single bearing
Voltage Regulation (No Load to Full Load) ±0.5 %
Power Factor 0.8
Armature Connection Star with Neutral/ Zig Zag
Excitation Brushless with AVR
No. Poles 4-pole
Frequency 60 Hz
Frequency Regulation (steady state load) ±0.25 %
Sound Level (Full Load at 23 ft.) 65 dB(A)

Engine Specifications

Make/Model Isuzu / BR-4JJ1X
Emissions EPA Tier 4 Final Certified
Starting System Electric
Design 4-cycle, water cooled, direct injection, turbocharged, DOC, SCR
Gross Engine Power Output 95.2 bhp 71 kW
Fuel Tank Capacity 103 gal 390 L
Fuel Consumption:
Full load 4.4 gph 16.6 lph
3/4 load 3.5 gph 13.4 lph
1/2 load 2.6 gph 9.8 lph
1/4 load 1.7 gph 6.4 lph
DEF Tank Capacity 7.4 gal 28L
Coolant Capacity 5.5 gal 21 L
Oil Capacity 3.96 gal 15 L
Battery 12V 75Ah x 1

TRLR70US Trailer Specifications

Gross Vehicle Weight Rating (GVWR) 7,000 lb 3,175 kg
Gross Axle Weight Rating (GAWR) (ea.) 3,500 lb 1,588 kg
Coupler Rating 3″ Pintle Eye (25,000 lb)
2″ Ball Coupler (10,000 lb)
2-5/16″ Ball Coupler (14,000 lb)
Tire Size ST205 / 75DI5 LR-C
Tire Load Rating (ea.) 1,825 lb 826 kg
Wheel Bolt Pattern 5 Lug on 4.5 in
Fits MQ Power Generator Models DCA70SSIU4F
DCA70USI3CAN

TRLR70US Dimensions & Weights

Overall Length 169.4 in 4,938 mm
Overall Width 72.5 in 1,841.5 mm
Overall Height 24.2 in 615 mm
Operating Weight
Without Fuel 1,089 lb 493.96 kg

TRLR75XF2 Trailer Specifications

Gross Vehicle Weight Rating (GVWR) 7,000 lb 3,175 kg
Gross Axle Weight Rating (GAWR) (ea.) 3,500 lb 1,588 kg
Coupler Rating 3″ Pintle Eye (25,000 lb)
2″ Ball Coupler (10,000 lb)
2-5/16″ Ball Coupler (14,000 lb)
Tire Size ST205 / 75D15 LR-C
Tire Load Rating (ea.) 1,850 lb 826 kg
Wheel Bolt Pattern 5 Lug on 4.5 in
Fuel Tank Capacity 100 gal 378.54 L
Combined Tank Runtime:
100% Load 46 h
Fits MQ Power Generator Models DCA70SSJU4F
DCA70SSIU4F
DCA45SSIU4F
DCA40SSKU4F2
DCA36SPXU4F
DCA25SSIU4F
DCA20SPXU4F
DCA15SPXU4F
DCA10SPXU4C
TLG8SSK4F2
DA7000SSA3

TRLR75XF2 Dimensions & Weights

Overall Length 151.3 in 3,843 mm
Overall Width 69.3 in 1,760 mm
Overall Height 24.8 in 599 mm
Operating Weight
With Fuel 2,077 lb 942 kg
Without Fuel 1,366 lb 619.6 kg

Documentation

Generator can be placed on MQ Trailer Models TRL70US and TRLR75XF2
Multiquip DCA70SSIU4F product and specifications and data sheet. Printable/downloadable pdf file shown in a pop up window.
Multiquip  TRLR70US traier no fuel tank product and specifications and data sheet. Printable/downloadable pdf file shown in a pop up window.
Multiquip TRLR75XF2 trailer 100 gallon tank specifications and data sheet. Printable/downloadable pdf file shown in a pop up window.
Multiquip

Related Media

WhisperWatt Generators Brochure
WhisperWatt Super-Silent Generators – 25 to 70 kVA Multi Phase – Spec Comparison Table
WhisperWatt Super-Silent Generators – 125 to 600 kVA Multi Phase – Spec Comparison Table
WhisperWatt Super-Silent Generators 6 to 36 kW Single Phase Spec Comparison Table
MQ Power Quick Reference Chart
WhisperWatt Generators ECU Controllers
PowerBalance Overview
Parallel Power Generation Overview
DEFTANK Product Brochure
MQ Power Filter Kits Flyer

Shipping

Flat rate shipping to a commercial location with a fork lift or loading dock will be added to each skid mount generator.  Estimated cost 1250.00 for the first generator and $800.00 for each additional generator. Extra fees for residential and lift gate service. Call for freight quote for trailer mounted generators.

Notice: Features and equipment specifications are subject to change without notice

Additional information

Weight 3858 oz
Dimensions 105.12 × 37.40 × 59.05 in
